Float and cord type level indicator

Float and cord type level indicator
Float and cord type level indicator
Product Code : FCLI 8800
Product Description

This Float and Cord type level indicator ( FCLI8800) Provides High reliability with high accuracy. It is Suitable for measurement of Liquid Level in Medium and Large Size Tanks.
This Liquid Level Measuring Device offers reliable operation even with Corrosive as well as aggressive acids and Liquids with fumes by coupling a transmitter to the dial, level alarm out put and 4-20mA, out put corresponding to the measuring range can be obtain

Features :

  • High Reliability
  • High Accuracy
  • Can be used with analogue to digital converter for transmission of tank level or alarms.
  • Special Version for
  • Corrosive applications.

Technical Specification :

Indication

Pointer

Measuring Range

2.5, 5, 10, 16, 20, 25 and 30 meters

Float

SS304, SS316, SS316L, PVC and PP

Tape

SS316

Bottom Anchor

MS, SS304, SS316 and SS316L

Housing

Die cast Aluminum

Protection

IP65

Accuracy

+ 2 mm

Least Count

1 mm

Maximum Temperature

200oC
