portable-8 channel

portable-8 channel
portable-8 channel
Product Code : 01
Product Description

Myko is a portable, battery operated data acquisition and logging system offering 16-bits, high-resolution, 8 channel data logging. The DaqPRO features powerful graphical display and analysis functions for measuring voltage, current and temperature. It is designed to provide a professional, compact, stand-alone low cost data logging system for a wide variety of applications.

Features :

  • High-end data acquisition hand-held mobile solution
  • 8 channels each capable of measuring seven popular parameters
  • Setup on every port makes it viable for all industries
  • Stand-alone operation: Display and keyboard for field programming and analysis (graph/table)
  • Rechargeable 7.2V battery with over 500 charging cycles
  • High sampling rate - up to 4,000 samples/second
  • Large data storage 512 KB RAM
  • Fast communication channels: USB
  • Multiple logging storage of up to 100 sampling sessions
  • Scales readings into meaningful engineering units e.g. bar, ppm
  • Built-in clock and calendar keeps track of time and date for each data recording
  • On screen text editing to annotate collected data
  • Value for money - less than $130 per channel

Specification :

Inputs (DaqPRO 5300) Selectable types for each input : 0-24 mA, 0-50 mV, 0-10V NTC, PT-100 Thermocople, Pulse and Frequency (input1 only) 0-24 mA

Range

0-24mA

Resolution

0.74A

Accuracy

+ 0.5%

Loop Impedance

21

0-50mV

Range

0-50V

Resolution

V

Accuracy

+ 0.5%

0-10V


Temperature NTC

10/100K resistor

Range

-25-150oC

Resolution

0.05oC

Accuracy

+ 0.5%

Temperature PT-100


Range

-200-400oC

Resolution

0.1 oC 7(m)

Accuracy

-200 to + 0.5%


50 to 40 + 0.5%


-50 to 40 + 0.5%

The daq Pro offers up to PT-100 2 wire channels or 4 PT-100 3 wire channels

Temperature Thermocouple J


Range

-200-1200oC

Resolution

0.1 oC (V)

Accuracy

-200 to + 0.5%


50 to 1.2 + 0.5%


-50 to 5 + 0.5%

Cold Junction compensation + 0.3%


Temperature Thermocouple K


Range

-250-1.200oC

Resolution

0.1 oC (V)

Accuracy

-200 to-5 + 0.5%


50 to 40 + 0.5%


-50 to 50 + 0.5%

Cold junction compensation + 0.3%


Internal Temperature


Range

-200-400oC

Resolution

0.1oC (V)

Accuracy

+ 0.3oC

Pulse Counter (Input 1 Only) Optocoupler Input


Range

0-65.000

Input Signal

0-5V

Input Impedance

470

Band Width

0.25 Hz

Frequency Meter (Input 1 Only) Optocoupler Input


Range

20-4.000 Hz

Input Signal

0-5V

Input Impedance

470
