Ultrasonic Level indictor Transmitter

Ultrasonic Level indictor Transmitter
Ultrasonic Level indictor Transmitter
Product Code : 09
Product Description

Ultraonic level meter is manufactured by MYKO ELECTRONIS Pvt. Ltd. absorbed many kinds of level meter advantage, achieve full digital, humanized design concept, now become our last update and high end products, use cast aluminum and waterproof housing, use international common appliance connector, with standard wire connector, easy to install, and with waterproof sealing cover, has perfect liquid level monitoring measuring, data transfer and human-machine communication features, use big display for the operation manu, can record ten interference echo point, use best available industrial class single chip, digital temperature compensation and use about ten relative specific IC Chip with wide input voltage. With a strong anti-interference, can be set for the upper and lower liquid level limitation and output adjust, also with on site display, selectable analog, switch and RS485 output, at the same time support RS485(Modbus) serial mode debug menu, to make up for the lack of display function, convenient interface and related facilities, also intelligent software design, for make up to no display, also can use external adjustment resistor to set internal parameters. easy to connect with the relative facility, no need to connect with industrial media to meet most of the level measurement requirements, accordingly, it can completely solve the blockage, leakage, corrosion, maintenance inconvenience shortcomings from the traditional measurement of pressure, capacitive, float type winding.

Applications :
Water and waste water treatment Pumping stations, collection wells, biochemical reactions pool, settling ponds Electricity, mining Mortar pool, coal slurry pond, water treatment

Technical Specification :

Range

0.3 - 5 M, 0.3 - 8 M, 0.5 -10M, 0.7 - 20 M, 1 - 30 M,

Blind Spot

<0.3 M

Sensor

ABS

Enclosure

IP 65

Proses Connection

1 1/2" BSP (M)/ Flanged

Launch angle

12o Minimum

Power Supply

24 VDC

Level Display

4 Digit LCD

Temperature

-10 oC to 75oC

Accuracy

+ 0.3 %
